OK1KIR EME Team - LOGs & Statistics, 24 GHz

24 GHz

Transvertor 24 GHz/145 MHz
TX/RX 24048 MHz CW or JT4G

Equipment:

– Solid dish 4.5m, f/D=0.42, el-az mount, tracking in 0.02° step
linear polarization horn, HPBW≈0.21°
– TS790 + audio filter Timewave DSP 59+
– rotatable TRX 24048MHz/145MHz (DB6NT design) + 2x 10W SSPA (DB6NT) in the dish focus point
– 1.4dB WG LNA (DB6NT)

First CW QSO on 9.3.2008 with DF1OI; First JT QSO with VK3XPD on 13.3.2013
WAC CW - worked Asia, Europe, North America and Oceania
WAC JT - worked Asia, Europe, North America and Oceania

ModeQSOInitialDXCCLocatorFieldUS StateWAC CQ ITU
ALL (CW/SSB/JT/QRA)126471547181469
ANALOG (CW/SSB)73221322111468
DIGITAL (JT/QRA)53351135131457

Area: Type of map: Mode:

World map: OK1KIR - Field map on 24 GHz band:  18 fields
